2024 Hustler Raptor XDX Kawasaki FR730 / 60”- HUS01343
Get in Touch
Description
2024 Hustler Raptor XDX Kawasaki FR730 / 60”
Raptor XDX
The Raptor® XDX is at the top of Hustler's residential zero-turn category. It has commercial-grade features like a 10-gauge fabricated deck, cast steel deck hangers, vented and tool-less removable pulley covers, and reaches up to 8mph with Hydro-Gear® ZT-3100® commercial transmissions. The 5-inch-deep deck is designed to allow for mowing through thick grass at top speeds. The heavy-duty XDX is backed by a 3yr / 300hr limited warranty and 1yr / 300hr commercial limited warranty.
Features May Include:
-
Welded Steel Deck
Welded fabricated steel deck helps add durability and can extend the mower's life. -
Wider Stance
Designed to provide ample room adding to the comfort for the operator. -
SmoothTrak Steering
Precision control designed to help trim and maneuver easily around obstacles. -
Bolstered Seat
Helps provide a comfortable ride with armrests and airflow to the back. -
Rubber Floor Mat
Helps provide comfort by minimizing vibration on the operator's feet. Standard on all Raptor models. -
Fabricated Frame
Continuous one-piece 1½ inch by 3 inch welded tubular frame. -
Foot-Operated Deck Lift
Easily adjust the deck height between 1.5" - 4.5". -
Easy to Service
Flip-up seat pan, removable floor pan, vented pulley covers. -
Exclusive BigBite Rear Tires
We worked directly with the tire manufacturer on this design. -
Kawasaki® Power
Powered by a V-Twin Kawasaki® Engine. -
Commercial Grade Deck
10 gauge steel and 11 gauge front bull nose bumper designed for durability. Up to 60” deck sizes available. -
Extra High-back Seat
An extra high-back seat (compared to the Raptor X seat) with armrests. -
22" BigBite™ Tires
Aggressive tire to help handle tough jobs.
Dealer Notes
Pricing may not include destination or setup charges. Get in touch with us for the most accurate price.
Description
The Raptor® XDX is at the top of Hustler's residential zero-turn category. It has commercial-grade features like a 10-gauge fabricated deck, cast steel deck hangers, vented and tool-less removable pulley covers, and reaches up to 8mph with Hydro-Gear® ZT-3100® commercial transmissions. The 5-inch-deep deck is designed to allow for mowing through thick grass at top speeds. The heavy-duty XDX is backed by a 3yr / 300hr limited warranty and 1yr / 300hr commercial limited warranty.
- 22" Bigbite™ Tires: Aggressive Tire To Help Handle Tough Jobs.
- Extra High-Back Seat: An Extra High-Back Seat (Compared To The Raptor X Seat) With Armrests.
- Commercial Grade Deck: 10 Gauge Steel And 11 Gauge Front Bull Nose Bumper Designed For Durability. Up To 60” Deck Sizes Available.
- Engine Manufacturer: Kawasaki FR730
- Engine Horsepower: 24
- Transmission: Hydro-Gear ZT-3100®
- Fuel Capacity: 3 gal.
- Ground Speed (Fwd): Up to 8 mph
- Cutting Width: 60"
- Cutting Height: 1.5" to 4.5"
- Front Tire: 13 x 6.5
- Drive Tire: 22 x 11-10 BigBite™
- Warranty: 3 Year/300 hour residential or 1 Year/300 hour commercial
- Engine Manufacturer: Kawasaki FR730
- Engine Horsepower: 24
- Displacement: 726cc
- Cooling: Air Cooled
- Engine Warranty: 3 Year Warranty
- Type: Dual Hydrostatic
- Transmission: Hydro-Gear ZT-3100®
- Fuel Capacity: 3 gal.
- Ground Speed (Fwd): Up to 8 mph
- Parking Brake: Integrated with steering levers
- Cutting Width: 60"
- Cutting Height: 1.5" to 4.5"
- Deck Depth: 5.0"
- Deck Lift: Foot Operated
- Number Of Blades: 3
- Blade Length: 20.50"
- Blade Tip Speed: 18,400
- Spindles: Aluminum with 1" shaft and sealed ball bearings
- Deck Engagement: Ogura GT1.5
- Deck Material: Fabricated 10 gauge steel
- Spindle Mounts: Reinforced 11 gauge steel
- Impact Trim Area: 11 ga. formed channel w/ rolled edge
- Frame: 1.5" X 3.0" steel tubing
- Front Axle: Fabricated with sealed ball bearings
- Front Caster Wheel: Sealed ball bearings
- Front Caster Fork: Fabricated 3/8" steel
- Seat: Bolstered extra high-back seat with armrests and built-in lumbar support
- Cup Holder: Yes
- Front Tire (Inches): 13 x 6.5
- Drive Tire (Inches): 22 x 11-10 BigBite™
- Weight (Lbs): 710
- Height (Inches): 43.7
- Length (Inches): 71.1
- Width W/ Chute Up (Inches): 62.2
- Tire-To-Tire Width (Inches): 48.6
- Productivity (Acres Per Hour): 3.88
- Warranty: 3 Year/300 hour residential or 1 Year/300 hour commercial
- Catcher Style: 2-bag
- Powered / Non-Powered: Powered
- Catcher Capacity: 7.2 bushel
- Mower Length W/ Catcher: 92.3
- Mower Width W/ Catcher: 69.2
Info
Industry
Power Equipment / Lawn
Make
Hustler
Model
Raptor XDX
Trim
Kawasaki FR730 / 60”
Year
2024
Price
6849.00
Stock Number
HUS01343
Category
Residential Lawn Mowers
Subcategory
Residential Lawn Mowers
Condition
New
Location
Wood Powersports - Harrison
Fuel Type
Gas
Serial Number
24101343
Specifications
Engine Type
Kawasaki FR730
Engine Displacement
726cc
Power
24 HP
Deck Size
60”
Warranty
Residential: 3 Year/300 hour | Commercial: 3 Year/300 hour | Engine: 3 Year Warranty
Transmission
Hydro-Gear ZT-3100
Fuel Capacity
3 gal
Tires
Front: 13 x 6.5 | Drive: 22 x 11-10 BigBite
Weight
710
Height
43.7
Length
71.1 | Mower W/ Catcher: 92.3
Width
Chute Up: 62.2 | Tire To Tire: 48.6 | Mower W/ Catcher: 69.2
Cutting Width
60”
